| Manufacturer Part Number: | APTGFQ25H120T2G |
|---|---|
| Manufacturer: | Microsemi Corporation |
| Product Category: | Transistors - IGBTs - Modules |
| Available Quantity: | 9151 Pieces |
| Unit Price: | Quote by Email |
| Description: | IGBT Module NPT and Fieldstop Full Bridge 1200V 40A 227W Through Hole SP2 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | APTGFQ25H120T2G Datasheet |
| Internal Part Number | 898-APTGFQ25H120T2G | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | APT Full Bridge Module Series | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - IGBTs - Modules | |
| Manufacturer | Microsemi Corporation | |
| Series | - | |
| Part Status | Not For New Designs | |
| IGBT Type | NPT and Fieldstop | |
| Configuration | Full Bridge | |
| Voltage - Collector Emitter Breakdown (Max) | 1200V | |
| Current - Collector (Ic) (Max) | 40A | |
| Power - Max | 227W | |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 25A | |
| Current - Collector Cutoff (Max) | 250µA | |
| Input Capacitance (Cies) @ Vce | 2.02nF @ 25V | |
| Input | Standard | |
| NTC Thermistor | Yes | |
| Mounting Type | Through Hole | |
| Package / Case | SP2 | |
| Supplier Device Package | SP2 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | APTGFQ25H120T2G | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
APTGFQ25H120T2G is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of APTGFQ25H120T2G is new and unused, you can buy APTGFQ25H120T2G Microsemi Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for APTGFQ25H120T2G.
