| Manufacturer Part Number: | BD746C-S |
|---|---|
| Manufacturer: | Bourns Inc. |
| Product Category: | Transistors - Bipolar (BJT) - Single |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | TRANS PNP 100V 20A |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | BD746C-S Datasheet |
| Internal Part Number | 898-BD746C-S | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | SOT-93 Bipolar Transistors 03/Apr/2012 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - Bipolar (BJT) - Single | |
| Manufacturer | Bourns Inc. | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Obsolete | |
| Transistor Type | PNP | |
| Current - Collector (Ic) (Max) | 20A | |
| Voltage - Collector Emitter Breakdown (Max) | 100V | |
| Vce Saturation (Max) @ Ib, Ic | 3V @ 5A, 20A | |
| Current - Collector Cutoff (Max) | 100µA | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 20 @ 5A, 4V | |
| Power - Max | 3.5W | |
| Frequency - Transition | - | |
| Mounting Type | Through Hole | |
| Package / Case | TO-218-3 | |
| Supplier Device Package | SOT-93 | |
| Standard Package | 300 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | BD746C-S | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
BD746C-S is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of BD746C-S is new and unused, you can buy BD746C-S Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for BD746C-S.
