| Manufacturer Part Number: | CSD16323Q3 |
|---|---|
| Manufacturer: | T-I |
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Available Quantity: | 34010 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOSFET N-CH 25V 3.3X3.3 8-SON |
| Lead Free Status / RoHS Status: | Contains lead / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CSD16323Q3 Datasheet |
| Internal Part Number | 898-CSD16323Q3 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | NexFET MOSFET Technology | |
| Video File | NexFET Power Block PowerStack™ Packaging Technology Overview | |
| Featured Product | Create your power design now with TI’s WEBENCH® Designer | |
| PCN Design/Specification | Qualification Revision A 01/Jul/2014 | |
| PCN Assembly/Origin | Qualification Assembly/Test Site 03/Mar/2014 Qualification Wire Bond 27/May/2014 Assembly/Test Site Revision C 09/Feb/2015 | |
| Manufacturer Product Page | CSD16323Q3 Specifications | |
| Online Catalog | N-Channel Logic Level Gate FETs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - Single | |
| Manufacturer | T I | |
| Series | NexFET™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Logic Level Gate | |
| Drain to Source Voltage (Vdss) | 25V | |
| Current - Continuous Drain (Id) @ 25°C | 21A (Ta), 60A (Tc) | |
| Rds On (Max) @ Id, Vgs | 4.5 mOhm @ 24A, 8V | |
| Vgs(th) (Max) @ Id | 1.4V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 8.4nC @ 4.5V | |
| Input Capacitance (Ciss) @ Vds | 1300pF @ 12.5V | |
| Power - Max | 3W | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerTDFN | |
| Supplier Device Package | 8-VSON (3.3x3.3) | |
| Standard Package | 2,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CSD16323Q3 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CSD16323Q3 is in stock for immediate shipping now. We are the distributor of T-I all series components. The condition of CSD16323Q3 is new and unused, you can buy CSD16323Q3 T-I with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CSD16323Q3.
