Manufacturer Part Number: | LM22677TJ-5.0/NOPB |
---|---|
Manufacturer: | T-I |
Product Category: | PMIC - Voltage Regulators - DC DC Switching Regulators |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Buck Switching Regulator IC Positive Fixed 5V 1 Output 5A TO-263-7 Thin |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | LM22677TJ-5.0/NOPB Datasheet |
Internal Part Number | 898-LM22677TJ-5.0/NOPB | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | SIMPLE SWITCHER® Regulators LM315x & LM2267x SIMPLE SWITCHER® and WEBENCH Powering FPGAs with SIMPLE SWITCHER® LMZ3 Power Modules | |
Video File | Wide VIN Power Design with LMZ3 SIMPLE SWITCHER Power Module SIMPLE SWITCHER® Power Modules with High Power Density SIMPLE SWITCHER Synchronous Regulator Family Overview The Most Interesting Engineer in the World Layout Tips for Radiated EMI Reduction in Your Designs Thermal Design Made Simple Loop Compensation Made SIMPLE WEBENCH PCB Export for Synchronous SIMPLE SWITCHER Devices | |
Design Resources | LM22677 Design with WEBENCH® Power Designer | |
Featured Product | Create your power design now with TI’s WEBENCH® Designer | |
PCN Design/Specification | LM22677,LM22677-Q1 Datasheet Update Rev 23/Oct/2015 | |
PCN Assembly/Origin | Wafer Fab Qualification 07/Oct/2014 | |
Manufacturer Product Page | LM22677TJ-5.0/NOPB Specifications | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
Manufacturer | T I | |
Series | SIMPLE SWITCHER® | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Function | Step-Down | |
Output Configuration | Positive | |
Topology | Buck | |
Output Type | Fixed | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 4.5V | |
Voltage - Input (Max) | 42V | |
Voltage - Output (Min/Fixed) | 5V | |
Voltage - Output (Max) | - | |
Current - Output | 5A | |
Frequency - Switching | 500kHz | |
Synchronous Rectifier | No | |
Operating Temperature | -40°C ~ 125°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | TO-263-7 Thin | |
Supplier Device Package | TO-263-7 Thin | |
Standard Package | 1,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | LM22677TJ-5.0/NOPB | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
