| Manufacturer Part Number: | PIC16F506-I/MG |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Embedded - Microcontrollers |
| Available Quantity: | 9011 Pieces |
| Unit Price: | Quote by Email |
| Description: | PIC PIC® 16F Microcontroller IC 8-Bit 20MHz 1.5KB (1K x 12) FLASH 16-QFN-EP (3x3) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PIC16F506-I/MG Datasheet |
| Internal Part Number | 898-PIC16F506-I/MG | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | 8-bit PIC® Microcontroller Portfolio | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | Mold Compound Update 31/Oct/2014 Lead Frame Update 16/Feb/2015 | |
| PCN Assembly/Origin | Qualification QFN-28,20,16 Packages 26/Dec/2013 Qualification QFN-28,20,16 with Copper 09/Jan/2014 Qualification Report 28/Jan/2014 Qualification Copper Wire Revison 01/Apr/2014 Cancelation of Copper Assembly 25/Jun/2015 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Manufacturer | Microchip Technology | |
| Series | PIC® 16F | |
| Packaging | Tray | |
| Part Status | Active | |
| Core Processor | PIC | |
| Core Size | 8-Bit | |
| Speed | 20MHz | |
| Connectivity | - | |
| Peripherals | POR, WDT | |
| Number of I/O | 11 | |
| Program Memory Size | 1.5KB (1K x 12) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 67 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2 V ~ 5.5 V | |
| Data Converters | A/D 4x8b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Package / Case | 16-VFQFN Exposed Pad | |
| Supplier Device Package | 16-QFN-EP (3x3) | |
| Standard Package | 120 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PIC16F506-I/MG | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PIC16F506-I/MG is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of PIC16F506-I/MG is new and unused, you can buy PIC16F506-I/MG Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PIC16F506-I/MG.
