Manufacturer Part Number: | STGY50NC60WD |
---|---|
Manufacturer: | STMicroelectronics |
Product Category: | Transistors - IGBTs - Single |
Available Quantity: | 9722 Pieces |
Unit Price: | Quote by Email |
Description: | IGBT 600V 110A 278W Through Hole MAX247™ |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | STGY50NC60WD Datasheet |
Internal Part Number | 898-STGY50NC60WD | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Other Related Documents | STGY50NC60WD View All Specifications | |
Featured Product | Tail-Less 600 V IGBT V Series | |
Online Catalog | Standard IGBTs | |
Category | Discrete Semiconductor Products | |
Family | Transistors - IGBTs - Single | |
Manufacturer | STMicroelectronics | |
Series | PowerMESH™ | |
Packaging | Tube | |
Part Status | Active | |
IGBT Type | - | |
Voltage - Collector Emitter Breakdown (Max) | 600V | |
Current - Collector (Ic) (Max) | 110A | |
Current - Collector Pulsed (Icm) | 180A | |
Vce(on) (Max) @ Vge, Ic | 2.6V @ 15V, 40A | |
Power - Max | 278W | |
Switching Energy | 365µJ (on), 560µJ (off) | |
Input Type | Standard | |
Gate Charge | 195nC | |
Td (on/off) @ 25°C | 52ns/240ns | |
Test Condition | 390V, 40A, 10 Ohm, 15V | |
Reverse Recovery Time (trr) | 55ns | |
Package / Case | TO-247-3 | |
Mounting Type | Through Hole | |
Supplier Device Package | MAX247™ | |
Standard Package | 30 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | STGY50NC60WD | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
STGY50NC60WD is in stock for immediate shipping now. We are the distributor of STMicroelectronics all series components. The condition of STGY50NC60WD is new and unused, you can buy STGY50NC60WD STMicroelectronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for STGY50NC60WD.
